Configure Your Machine for a Wireless Network Using the PIN Method of Wi-Fi Protected Setup (WPS)

If your wireless LAN access point/router supports WPS, you can use the Personal Identification Number (PIN) Method to configure your wireless network settings.

The PIN Method is one of the connection methods developed by the Wi-Fi Alliance®. By submitting a PIN created by an Enrollee (your machine) to the Registrar (a device that manages the wireless LAN), you can set up the wireless network and security settings. For more information on how to access WPS mode, see the instructions provided with your wireless access point/router.

Type A
Connection when the wireless LAN access point/router (1) doubles as the Registrar:
Type B
Connection when another device (2), such as a computer, is used as the Registrar:
Routers or access points that support WPS are marked with this symbol:

DCP-L2531DW/DCP-L2535DW/DCP-L2550DW/MFC-L2710DW/MFC-L2713DW/MFC-L2715DW/MFC-L2716DW

  1. Press Menu.
  2. Press image or image to select the [Network] option, and then press OK.
  3. Press image or image to select the [WLAN] option, and then press OK.
  4. Press image or image to select the [WPS w/PIN Code] option, and then press OK.
  5. When [WLAN Enable?] appears, enable the wireless network.
    This will start the wireless setup wizard.
  6. The LCD displays an eight-digit PIN and the machine starts searching for a wireless LAN access point/router.
  7. Using a computer connected to the network, in your browser's address bar, type the IP address of the device you are using as the Registrar. (For example: http://192.168.1.2)
  8. Go to the WPS settings page and type the PIN, and then follow the on-screen instructions.
    • The Registrar is usually the wireless LAN access point/router.
    • The settings page will differ depending on the brand of wireless LAN access point/router. For more information, see the instructions supplied with your wireless LAN access point/router.
If you are using a Windows 7, Windows 8, or Windows 10 computer as a Registrar, complete the following steps:
  1. Do one of the following:
    • Windows 7

      Click image (Start)>Devices and Printers>Add a device.

    • Windows 8

      Move your mouse to the lower right corner of your desktop. When the menu bar appears, click Settings>Control Panel>Hardware and Sound>View devices and printers>Add a device.

    • Windows 10

      Click image>Windows System>Control Panel. In the Hardware and Sound group, click Add a device.

    • To use a Windows 7, Windows 8, or Windows 10 computer as a Registrar, you must register it to your network in advance. For more information, see the instructions supplied with your wireless LAN access point/router.
    • If you use Windows 7, Windows 8, or Windows 10 as a Registrar, you can install the printer driver after the wireless configuration by following the on-screen instructions. To install the full driver and software package, use the Brother installation disc.
  2. Select your machine and click Next.
  3. Type the PIN displayed on the machine's LCD, and then click Next.
  4. (Windows 7) Select your network, and then click Next.
  5. Click Close.
If your wireless device is connected successfully, the machine's LCD displays [Connected].

You have completed the wireless network setup. To install Full Driver & Software Package necessary for operating your device, insert the Brother installation disc into your computer or go to your model's Downloads page on the Brother Solutions Center at support.brother.com.

HL-L2395DW/MFC-L2730DW/MFC-L2750DW/MFC-L2751DW/MFC-L2770DW/MFC-L2771DW

  1. Press image[Settings]>[All Settings]>[Network]>[WLAN]>[WPS w/ PIN Code].
  2. When [Switch Network interface to wireless?] appears, press [Yes].
    This will start the wireless setup wizard. To cancel, press [No].
  3. The LCD displays an eight-digit PIN and the machine starts searching for a wireless LAN access point/router.
  4. Using a computer connected to the network, in your browser's address bar, type the IP address of the device you are using as the Registrar. (For example: http://192.168.1.2)
  5. Go to the WPS settings page and type the PIN, and then follow the on-screen instructions.
    • The Registrar is usually the wireless LAN access point/router.
    • The settings page will differ depending on the brand of wireless LAN access point/router. For more information, see the instructions supplied with your wireless LAN access point/router.
If you are using a Windows 7, Windows 8, or Windows 10 computer as a Registrar, complete the following steps:
  1. Do one of the following:
    • (Windows 7)

      Click image (Start)>Devices and Printers>Add a device.

    • (Windows 8)

      Move your mouse to the lower right corner of your desktop. When the menu bar appears, click Settings>Control Panel>Hardware and Sound>View devices and printers>Add a device.

    • To use a Windows 7, or Windows 8 computer as a Registrar, you must register it to your network in advance. For more information, see the instructions supplied with your wireless LAN access point/router.
    • If you use Windows 7 or Windows 8 as a Registrar, you can install the printer driver after the wireless configuration by following the on-screen instructions. To install the full driver and software package, use the Brother installer on the Installer CD-ROM.
  2. Select your machine and click Next.
  3. Type the PIN displayed on the machine's LCD, and then click Next.
  4. (Windows 7) Select your network, and then click Next.
  5. Click Close.
If your wireless device is connected successfully, the machine's LCD displays [Connected].

You have completed the wireless network setup. To install Full Driver & Software Package necessary for operating your device, insert the Brother installation disc into your computer or go to your model's Downloads page on the Brother Solutions Center at support.brother.com.
