Specifications

General Specifications

Printer Type

  • Laser

Print Method

  • Electrophotographic Laser Printer

Memory Capacity

Standard

  • (DCP-7090DW/DCP-L2535DW/DCP-L2550DW/DCP-7190DW)

    128 MB

  • (DCP-7195DW/MFC-7895DW)

    256 MB

LCD (Liquid Crystal Display)

  • (DCP-7090DW/DCP-L2535DW/DCP-L2550DW/DCP-7190DW)

    10 characters (2 byte) x 2 lines

  • (DCP-7195DW/MFC-7895DW)

    2.7 in. (67.5 mm) TFT Colour touchscreen LCD *1

Power Source

  • 220 to 240 V AC 50/60 Hz

Power Consumption

(Average)

Peak

  • Approximately 1104 W

Printing *2

  • (DCP-7195DW/MFC-7895DW)

    Approximately 475 W at 25 °C

  • (DCP-7090DW/DCP-L2535DW/DCP-L2550DW/DCP-7190DW)

    Approximately 475 W at 25 °C

Printing

(Quiet Mode) *2

  • Approximately 260 W at 25 °C

Copying *2

  • (DCP-7195DW/MFC-7895DW)

    Approximately 485 W at 25 °C

  • (DCP-7090DW/DCP-L2535DW/DCP-L2550DW/DCP-7190DW)

    Approximately 485 W at 25 °C

Copying

(Quiet Mode) *2

  • Approximately 260 W at 25 °C

Ready *2

  • Approximately 42 W at 25 °C

Sleep *2

  • (DCP-7195DW/MFC-7895DW)

    Approximately 6.4 W

  • (DCP-7090DW/DCP-L2535DW/DCP-L2550DW/DCP-7190DW)

    Approximately 6.2 W

Deep Sleep *2

  • (DCP-7195DW/MFC-7895DW)

    Approximately 1.1 W

  • (DCP-7090DW/DCP-L2535DW/DCP-L2550DW/DCP-7190DW)

    Approximately 0.9 W

Power Off *2 *3 *4

  • Approximately 0.03 W

Dimensions

(Typical outline view)

(DCP-7090DW/DCP-L2535DW)


(DCP-L2550DW/DCP-7190DW)


(DCP-7195DW)


(MFC-7895DW)


Unit: mm

  • (DCP-7090DW/DCP-L2535DW)

    * : 410

    ** : 272

    *** : 398.5

  • (DCP-L2550DW/DCP-7190DW)

    * : 410

    ** : 318.5

    *** : 398.5

  • (DCP-7195DW)

    * : 410

    ** : 318.5

    *** : 426.5

  • (MFC-7895DW)

    * : 481

    ** : 318.5

    *** : 426.5

Weights (with supplies)

  • (DCP-7090DW/DCP-L2535DW)

    10.3 kg

  • (DCP-L2550DW/DCP-7190DW)

    11.6 kg

  • (DCP-7195DW)

    12.1 kg

  • (MFC-7895DW)

    12.8 kg

Noise Level

Sound Pressure

Printing

  • LpAm = 49 dB (A)

Printing

(Quiet Mode)

  • LpAm = 44 dB (A)

Ready

  • LpAm = 30 dB (A)

Sound Power

Printing

  • LWAd = 6.59 B (A)

Printing

(Quiet Mode)

  • LWAd = 6.11 B (A)

Ready

  • LWAd = Inaudible

Temperature

Operating

  • From 10°C to 32°C  *5

Storage

  • From 0°C to 40°C

Humidity

Operating

  • 20 to 80% (without condensation)

Storage

  • 35 to 85% (without condensation)

Automatic Document Feeder (ADF)

(DCP-L2550DW/DCP-7190DW/DCP-7195DW/MFC-7895DW)

  • (DCP-L2550DW/DCP-7190DW/DCP-7195DW/MFC-7895DW)

    Up to 50 sheets

For best results we recommend:

  • Temperature: 20 to 30 °C

  • Humidity: 50 to 70%

  • Paper: 80 g/m2

*1
Measured diagonally.
*2
USB connections to computer
*3
Measured according to IEC 62301 Edition 2.0.
*4
Power consumption varies slightly depending on the usage environment.
*5
To ensure the high print quality, the maximum ambient temperature we recommend is 32 °C. The maximum ambient temperature to safely use this machine is 35 °C.

Document Size Specification

Document Size

ADF Width *1

  • 105 mm to 215.9 mm

ADF Length *1

  • 147.3 mm to 355.6 mm

Scanner Glass Width

  • Maximum 215.9 mm

Scanner Glass Length

  • Maximum 300 mm

*1
ADF models only

Print Media Specifications

Paper Input

Paper Tray

(Standard)

Paper Type

  • Plain Paper, Thin Paper, Recycled Paper, Thick Paper

Paper Size

  • A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, 16K (195x270mm)

Paper Weight

  • 60 to 163 g/m2

Maximum Paper Capacity

  • Up to 250 sheets of 80 g/m2 Plain Paper

Manual Feed Slot

(DCP-7090DW/DCP-L2535DW/DCP-L2550DW/DCP-7190DW )

Paper Type

  • Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env. Thin, Env.Thick

Paper Size

  • Width:

    76.2 to 215.9 mm

  • Length:

    127 to 355.6 mm

  • Envelope:

    COM-10, DL, C5, Monarch

Paper Weight

  • 60 to 230 g/m2

Maximum Paper Capacity

  • One sheet at a time

Multi-Purpose Tray (MP tray)

(DCP-7195DW/MFC-7895DW )

Paper Type

  • Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env. Thin, Env.Thick

Paper Size

  • Width:

    76.2 to 215.9 mm

  • Length:

    127 to 355.6 mm

  • Envelope:

    COM-10, DL, C5, Monarch

Paper Weight

  • 60 to 230 g/m2

Maximum Paper Capacity

  • Up to 30 sheets of 80 g/m2 Plain Paper

  • Envelope: 2 envelopes

Paper Output *1

Face Down Output Tray

  • Up to 120 Sheets (face down delivery to the face down output paper tray) *2

Face Up Output Tray

  • One sheet (face up delivery to the face up output tray)

2-sided

Automatic 2-sided Printing

Paper Type

  • Plain Paper, Thin Paper, Recycled Paper

Paper Size

  • A4

Paper Weight

  • 60 to 105 g/m2

*1
For labels, we recommend removing the printed sheets from the output paper tray immediately after they exit the machine to avoid the possibility of smudging.
*2
Calculated with 80 g/m2 in a temperate, non humid environment.

Fax Specifications

NOTE

This feature is available for MFC models.

Compatibility

  • ITU-T Super Group 3

Coding System

  • MH / MR / MMR / JBIG

Modem Speed

  • 33,600 bps (with Automatic Fallback)

2-sided Print Receiving

  • (MFC-7895DW)

    Yes

Automatic 2-sided Sending

  • (MFC-7895DW)

    Yes (from ADF)

Scanning Width

  • Maximum 208 mm

Printing Width

  • Maximum 208 mm

Greyscale

  • 8 bit / 256 levels

Resolution

Horizontal

  • 203 dpi

Vertical

  • Standard: 98 dpi

  • Fine: 196 dpi

  • Photo: 196 dpi

Address Book

  • (MFC-7895DW)

    200 Locations

Groups

  • Up to 20

Broadcasting

  • (MFC-7895DW)

    250 Locations

Automatic Redial

  • 3 times at 5-minute intervals

Memory Transmission

  • (MFC-7895DW)

    Up to 500 pages *1

Out of Paper Reception

  • (MFC-7895DW)

    Up to 500 pages *1

*1
‘Pages’ refers to the ‘ITU-T Test Chart #1’ (a typical business letter, Standard resolution, JBIG code).

Copy Specification

Copy Width

  • Maximum 210 mm

Automatic 2-sided Copy

  • (MFC-7895DW)

    Yes (from ADF)

Sort Copy

  • Yes

Stack Copy

  • Up to 99 pages

Enlarge/Reduce

  • 25 to 400% (in increments of 1%)

Resolution

  • Maximum 600 x 600 dpi

First Copy Out Time *1

  • (DCP-7090DW/DCP-L2535DW/DCP-L2550DW/DCP-7190DW)

    Less than 10 seconds at 23 °C / 230 V

  • (DCP-7195DW/MFC-7895DW)

    Less than 9 seconds at 23 °C / 230 V
*1
From Ready Mode and standard tray

Scanner Specifications

Colour / Black

  • Yes / Yes

TWAIN Compliant

  • Yes

    (Windows 7 SP1 / Windows 8 / Windows 8.1 / Windows 10)

    (macOS v10.10.5, v10.11.x, v10.12.x, v10.13.x, v10.14.x, v10.15.x)

WIA Compliant

  • Yes

    (Windows 7 SP1 / Windows 8 / Windows 8.1 / Windows 10)

AirPrint Compliant

  • Yes

    (macOS v10.10.5, v10.11.x, v10.12.x)

Colour Depth

  • 30 bit colour Processing (Input)

  • 24 bit colour Processing (Output)

Grey Scale

  • 10 bit colour Processing (Input)

  • 8 bit colour Processing (Output)

Resolution *2

  • Up to 19200 x 19200 dpi (interpolated)

  • Up to 1200 x 1200 dpi (from Scanner Glass)

  • Up to 600 x 600 dpi (from ADF) *1

Scanning Width

  • Maximum 210 mm

Automatic 2-sided Scanning

  • (MFC-7895DW)

    Yes (from ADF)

*1
ADF models only
*2
Maximum 1200 × 1200 dpi scanning with the WIA driver in Windows 7, Windows 8, Windows 8.1 and Windows 10 (resolution up to 19200 × 19200 dpi can be selected by using the scanner utility)

Printer Specifications

Automatic 2-sided Print

  • Yes

Emulation

  • PCL6, BR-Script3, PDF Version 1.7

Resolution

  • 600 x 600 dpi, HQ1200 (2400 x 600 dpi) quality, 1200 x 1200 dpi

    (HQ1200 is a Brother image processing technology that enables vivid, sharp and smooth quality of printing.)

Print Speed *1  *2

1-sided print

  • Up to 34 pages/minute (A4 size)

    Up to 36 pages/minute (Letter size)

2-sided Print

  • Up to 16 pages/minute (Up to 8 sheets/minute) (A4 size)

    Up to 17 pages/minute (Up to 8.5 sheets/minute) (Letter size)

First Print Time *3

  • (DCP-7090DW/DCP-L2535DW/DCP-L2550DW/DCP-7190DW)

    Less than 8.5 seconds at 23 °C / 230 V

  • (DCP-7195DW/MFC-7895DW)

    Less than 7 seconds at 23 °C / 230 V
*1
The print speed may change depending on the type of document you print.
*2
Print speed may be slower when the machine is connected by wireless LAN.
*3
From Ready mode and standard tray

Interface Specifications

USB *1 *2

  • Hi-Speed USB 2.0

    Use a USB 2.0 interface cable that is no more than 2 metres long.

LAN

  • (DCP-L2550DW/DCP-7190DW/DCP-7195DW/MFC-7895DW)

    10Base-T/100Base-TX *3

Wireless LAN

  • IEEE 802.11b/g/n (Infrastructure Mode)

    IEEE 802.11g/n (Wi-Fi Direct®)

NFC

  • (DCP-7195DW/MFC-7895DW)

    Yes

*1
Your machine has a USB 2.0 Hi-Speed interface. The machine can also be connected to a computer that has a USB 1.1 interface.
*2
Third party USB ports are not supported.
*3
Use a straight-through Category 5 (or greater) twisted-pair cable.

Supported Protocols and Security Features

Ethernet

10Base-T/100Base-TX

Wireless LAN

IEEE 802.11b/g/n (Infrastructure Mode), IEEE 802.11g/n (Wi-Fi Direct)

Protocols (IPv4)

ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client

Protocols (IPv6)

NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, SMTP Client, FTP Client and Server, CIFS Client, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, Web Services (Print/Scan)

Network Security (Wired)

SMTP-AUTH, SSL/TLS (SMTP, HTTP, IPP), SNMP v3

Network Security (Wireless)

SMTP-AUTH, SSL/TLS (SMTP, HTTP, IPP), SNMP v3

Wireless Network Security

WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES)(Wi-Fi Direct supports WPA2-PSK (AES) only)

Wireless Certification

Wi-Fi Certification Mark License (WPA™/WPA2™ - Personal), Wi-Fi Protected Setup (WPS) Identifier Mark License, Wi-Fi CERTIFIED™ Wi-Fi Direct

Computer Requirements Specifications

Supported Operating Systems And Software Functions

For DCP-7195DW/MFC-7895DW

Computer Platform & Operating System Version PC Interface Processor For Drivers Hard Disk Space to Install

Parallel

(IEEE1284)

USB *1

10Base-T/100Base-TX

(Ethernet)

Wireless

802.11b/g/n

Windows Operating System

Windows 7 SP1 / 8 / 8.1 *2 *3

N/A

Printing

PC Fax *4

Scanning

32 bit (x86) or 64 bit (x64) processor

650 MB

1.2 GB

Windows 10 Home / 10 Pro / 10 Education / 10 Enterprise *2 *3

Windows Server 2008

N/A

Printing

50 MB

N/A

Windows Server 2008 R2

64 bit (x64) processor

Windows Server 2012

Windows Server 2012 R2

Windows Server 2016

Mac Operating System

macOS v10.10.5

Printing

PC-Fax (Send) *4

Scanning

Intel® Processor

80 MB

400 MB

macOS v10.11.x

macOS v10.12.x

*1
Third party USB ports are not supported.
*2
For WIA, 1200x1200 resolution. Brother Scanner Utility enables resolutions up to 19200 x 19200 dpi.
*3
PaperPort™ 14SE supports Windows 7, Windows8, Windows 8.1 and Windows 10.
*4
PC-Fax supports black and white only.

For DCP-L2535DW/DCP-L2550DW/DCP-7090DW/DCP-7190DW

Computer Platform & Operating System Version PC Interface Processor For Drivers Hard Disk Space to Install

Parallel

(IEEE1284)

USB *1

10Base-T/100Base-TX

(Ethernet)

 *2

Wireless

802.11b/g/n

Windows Operating System

Windows 7 SP1 / 8 / 8.1 *3 *4

N/A

Printing

Scanning

32 bit (x86) or 64 bit (x64) processor

650 MB

1.2 GB

Windows 10 Home / 10 Pro / 10 Education / 10 Enterprise *3 *4

Windows Server 2008

N/A

Printing

50 MB

N/A

Windows Server 2008 R2

64 bit (x64) processor

Windows Server 2012

Windows Server 2012 R2

Windows Server 2016

Windows Server 2019

Mac Operating System

macOS v10.10.5

Printing

Scanning

Intel® Processor

80 MB

400 MB

macOS v10.11.x

macOS v10.12.x

macOS v10.13.x

macOS v10.14.x

macOS v10.15.x

*1
Third party USB ports are not supported.
*2
Available only for DCP-L2550DW/DCP-7190DW.
*3
For WIA, 1200x1200 resolution. Brother Scanner Utility enables resolutions up to 19200 x 19200 dpi.
*4
PaperPort™ 14SE supports Windows 7, Windows8, Windows 8.1 and Windows 10.

For the latest driver updates, go to your model's Downloads page on the Brother Solutions Center at support.brother.com.

All trademarks, brand and product names are the property of their respective companies.

Related Information
Was this page helpful?

Yes

No

find moreaccept
