Front View and Back View

Front View

Front View

Back View


  1. Touch panel with touchscreen LCD
  2. Face-down output tray support flap
  3. Face-down output tray
  4. Paper tray
  5. Multi-purpose tray (MP tray) cover
  6. Front cover
  7. Multi-purpose tray (MP tray)
  8. USB accessory port (Front)
  9. 10BASE-T / 100BASE-TX / 1000BASE-T port
  10. USB port
  11. USB accessory port (Rear) (HL-L8570CDW)
  12. 2‑sided tray
  13. AC power connector / cord
  14. Back cover (Face-up output tray)
