Specifications

General Specifications

Printer Type

Inkjet

Print Head
Mono

Piezo with 420 nozzles x 1

Colour

Piezo with 420 nozzles x 3

Memory Capacity

  • 512 MB

LCD (liquid crystal display) *1
  • MFC-J5010DW/MFC-J5013DW

    2.7 in. (6.8 cm) TFT Colour Touchscreen LCD

  • MFC-J5110DW/MFC-J5115DW/MFC-J5117DW

    4.3 in. (10.9 cm) TFT Colour Touchscreen LCD

Power Source

AC 220 to 240 V 50/60 Hz

Power Consumption *2

  • MFC-J5010DW/MFC-J5013DW

    Copying *3: Approx. 33 W

    Ready *4: Approx. 4.5 W

    Sleep *4: Approx. 0.9 W

    Power Off *4 *5: Approx. 0.03 W

  • MFC-J5110DW

    Copying *3: Approx. 33 W

    Ready *4: Approx. 5.0 W

    Sleep *4: Approx. 0.9 W

    Power Off *4 *5: Approx. 0.03 W

  • MFC-J5115DW

    Copying *3: Approx. 33 W

    Ready *4: Approx. 5.0 W

    Sleep *4: Approx. 0.9 W

    Power Off *4 *5: Approx. 0.03 W

  • MFC-J5117DW

    Copying *3: Approx. 33 W

    Ready *4: Approx. 6.0 W

    Sleep *4: Approx. 0.9 W

    Power Off *4 *5: Approx. 0.03 W

Dimensions

  • MFC-J5010DW/MFC-J5013DW

    a: 435 mm

    b: 273 mm

    c: 439 mm

    d: 633 mm


  • MFC-J5110DW

    a: 435 mm

    b: 340 mm

    c: 415 mm

    d: 439 mm

    e: 690 mm


  • MFC-J5115DW

    a: 435 mm

    b: 340 mm

    c: 415 mm

    d: 489.5 mm

    e: 690 mm


  • MFC-J5117DW

    a: 435 mm

    b: 407 mm

    c: 482 mm

    d: 489.5 mm

    e: 690 mm

Weights

  • MFC-J5010DW

    14.0 kg

  • MFC-J5013DW

    14.0 kg

  • MFC-J5110DW

    17.1 kg

  • MFC-J5115DW

    17.5 kg

  • MFC-J5117DW

    20.0 kg

Noise Level
Sound Pressure *6
Operating
  • Printing

    53.5 dB(A) (Approx.)

  • Copying (using the scanner glass)

    52.5 dB(A) (Approx.)

Sound Power *7
Printing *8

  • LWAc = 6.88 B(A) (Mono)

    LWAc = 6.81 B(A) (Colour)

Temperature
Operating

10 to 35°C

Best Print Quality

20 to 33°C

Humidity
Operating

20 to 80% (without condensation)

Best Print Quality

20 to 80% (without condensation)

Automatic Document Feeder (ADF)

Up to 50 pages

Paper: 80 g/m²

*1
Measured diagonally.
*2
Measured when the machine is connected using the same network connection as the ENERGY STAR Ver. 3.2 test method. Power consumption varies slightly depending on the usage environment or part wear.
*3
When using ADF, single-sided printing and scanning, resolution: standard / document: ISO/IEC 24712 printed pattern.
*4
Measured according to IEC 62301 Edition 2.0.
*5
Even when the machine is turned off, it will automatically turn itself on periodically for print head maintenance, and then turn itself off.
*6
Noise depends on printing conditions.
*7
Measured in accordance with the method described in ISO 7779.
*8

Print speed:

  • 28 ipm (Mono) / 26 ipm (Colour)

These print speeds are for 1-sided printing and measured in accordance with the ISO/IEC 24734 standard.

Document Size Specifications

Document Size
ADF Width

105 to 215.9 mm

ADF Length *1

148 to 355.6 mm

Scanner Glass Width

Max. 215.9 mm

Scanner Glass Length

Max. 297 mm

*1
Up to 900 mm when using the long paper function.

Print Media Specifications

Paper Input Paper Tray #1 Paper Type *1

Plain Paper, Inkjet Paper (coated paper), Glossy Paper, Recycled Paper

Paper Size

  • A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive, A5, A6, Envelopes (C5, Com-10, DL, Monarch), Photo (10 x 15 cm), Photo L (9 x 13 cm), Photo 2L (13 x 18 cm), Index card (13 x 20 cm)
Maximum Paper Capacity

Up to 250 sheets of 80 g/m² Plain Paper

Paper Tray #2

(MFC-J5110DW/MFC-J5115DW/MFC-J5117DW)

Paper Type

Plain Paper, Recycled Paper

Paper Size

  • A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive, A5
Maximum Paper Capacity

Up to 250 sheets of 80 g/m² Plain Paper

Paper Tray #3

(MFC-J5117DW)

Paper Type

Plain Paper, Recycled Paper

Paper Size

  • A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive
Maximum Paper Capacity

Up to 250 sheets of 80 g/m² Plain Paper

Multi-purpose Tray (MP Tray)

(MFC-J5110DW/MFC-J5115DW/MFC-J5117DW)

Paper Type *1

Plain Paper, Inkjet Paper (coated paper), Glossy Paper, Recycled Paper

Paper Size / Maximum Paper Capacity

  • A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive, A5, A6, Envelopes (C5, Com-10, DL, Monarch), Photo (10 x 15 cm), Photo L (9 x 13 cm), Photo 2L (13 x 18 cm), Index card (13 x 20 cm)

Up to 100 sheets of 80 g/m² Plain Paper

Long Paper (Width: 88.9 - 215.9 mm / Height: 355.7 - 1200 mm)

Up to 1 sheet

Manual Feed Slot

(MFC-J5010DW/MFC-J5013DW) 		Paper Type *1

Plain Paper, Inkjet Paper (coated paper), Glossy Paper, Recycled Paper

Paper Size

  • A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive, A5, A6, Envelopes (C5, Com-10, DL, Monarch), Photo (10 x 15 cm), Photo L (9 x 13 cm), Photo 2L (13 x 18 cm), Index card (13 x 20 cm)
Maximum Paper Capacity

Up to 1 sheet

Paper Output *1
  • Up to A4/Letter size paper

    Up to 150 sheets of 80 g/m² Plain Paper (face up print delivery to the output paper tray)

  • Over A4/Letter size paper

    Up to 50 sheets of 80 g/m² Plain Paper (face up print delivery to the output paper tray)

*1
For glossy paper, remove any printed pages from the output paper tray immediately to avoid smudging.

Printer Specifications

Emulation

(MFC-J5110DW/MFC-J5115DW/MFC-J5117DW)

PCL6, BR-Script3, PDF version 2.0

Resolution

Up to 1200 × 4800 dpi

Printing Width *1

204 mm

Borderless *2: 210 mm

Borderless

A4, Letter, Legal, Mexico Legal, India Legal, Folio, A6, Photo (10 x 15 cm), Photo L (9 x 13 cm), Photo 2L (13 x 18 cm), Index card (13 x 20 cm)

Automatic 2-sided Printing

Paper Type

Plain Paper, Recycled Paper

Paper Size

A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive, A5

Print Speed

See your model's page on your local Brother website.

*1
When printing on A4 size paper.
*2
When the Borderless feature is set to On.

Scanner Specifications

Colour/Monochrome

Yes/Yes

TWAIN Compliant

Yes

(Windows 10 / Windows 11)

WIA Compliant

Yes

(Windows 10 / Windows 11)

Colour Depth

48 bit colour processing (Input)

24 bit colour processing (Output)

Greyscale

16 bit colour processing (Input)

8 bit colour processing (Output)

Resolution

Up to 19200 × 19200 dpi (interpolated) *1

Up to 1200 × 2400 dpi (optical) (from Scanner Glass)

Up to 600 × 600 dpi (optical) (from ADF)

Scanning Width and Length

(Single-sided document)

(Scanner Glass)

Width: Up to 213.9 mm

Length: Up to 295 mm

(ADF)

Width: Up to 213.9 mm

Length: Up to 353.6 mm

Scanning Width and Length

(2-sided document)

Width: Up to 213.9 mm (ADF)

Length: Up to 353.6 mm (ADF)

*1
The TWAIN driver only (Maximum 1200 × 1200 dpi scanning with the WIA driver in Windows 10 and Windows 11.)

Copy Specifications

Colour/Monochrome

Yes/Yes

Copy Width

204 mm *1

Multiple Copies

Stacks/Sorts up to 999 pages

Enlarge/Reduce

25% to 400% (in increments of 1%)

Resolution

Prints up to 1200 × 4800 dpi

Automatic 2-sided Copy
Paper Type

Plain Paper, Recycled Paper

Paper Size

A4, Letter, Legal, Mexico Legal, India Legal, Folio, A5

*1
When copying on A4 size paper.

Fax Specifications

Compatibility

  • MFC-J5010DW/MFC-J5013DW

    ITU-T Group 3

  • MFC-J5110DW/MFC-J5115DW/MFC-J5117DW

    ITU-T Super Group 3

Modem Speed

  • MFC-J5010DW/MFC-J5013DW

    Automatic Fallback: 14,400 bps

  • MFC-J5110DW/MFC-J5115DW/MFC-J5117DW

    Automatic Fallback: 33,600 bps

Scanning Width

ADF: 208 mm (A4)

Scanner Glass: 204 mm (A4)

Printing Width

204 mm (A4)

Automatic 2-sided Sending
Yes (from the ADF)
Greyscale

Monochrome: 8 bit (256 levels)

Colour: 24 bit (8 bit per colour/ 256 levels)

Resolution

(Horizontal)

203 dpi

Resolution

(Vertical)

Standard:

98 dpi (Mono)

196 dpi (Colour)

Fine:

196 dpi (Mono)

196 dpi (Colour)

Superfine:

392 dpi (Mono)

Photo:

196 dpi (Mono)

Address Book

100 names x 2 numbers or Email addresses

Groups

Up to 6

Broadcasting

250 (200 Address Book/50 Manual Dial)

Automatic Redial

3 times at 5 minute intervals

Memory Transmission

Up to 150 pages *1

Out of Paper Reception

Up to 150 pages *1

*1
‘Pages’ refers to the ‘ITU-T Test Chart #1’ (a typical business letter, Standard resolution, MMR code).

USB Flash Drive Specifications

Compatible Media

USB Flash drive *1

JPEG Print
Resolution

Up to 1200 x 4800 dpi

Paper Type

Plain Paper, Inkjet Paper (coated paper), Glossy Paper, Recycled Paper

Paper Size

A4, Letter, Photo (10 x 15 cm), Photo 2L (13 x 18 cm)

File Format

JPEG (Progressive JPEG format is not supported)

PDF Print

(MFC-J5110DW/MFC-J5115DW/MFC-J5117DW)

Resolution

Up to 1200 x 1800 dpi

Paper Type

Plain Paper, Recycled Paper

Paper Size

A4, Letter, Legal, Mexico Legal, India Legal, Folio, A5, A6

File Format

PDF version 2.0

Scan to Media
File Format

JPEG, PDF (Colour, Grey)

TIFF, PDF (Monochrome)

*1
USB Flash drive is not included. USB Mass Storage standard. Supported formats: FAT12/FAT16/FAT32/exFAT

Interface Specifications

USB *1 *2

Use a USB 2.0 interface cable (TypeA/B) that is no longer than 5 m.

LAN

Use a straight-through Category 5e (or greater) twisted-pair cable for 10Base-T/100Base-TX/1000Base-T.

Wireless LAN

IEEE 802.11a/b/g/n (Infrastructure)

IEEE 802.11a/g/n (Wi-Fi Direct)

NFC

(MFC-J5115DW/MFC-J5117DW)

Yes

*1
Your machine has a USB 2.0 Hi-Speed interface. The machine can also be connected to a computer that has a USB 1.1 interface.
*2
Third party USB ports are not supported.

Network Specifications


  • You can connect your machine to a network for Network Printing, Network Scanning, PC-Fax Send, and PC-Fax Receive (Windows only).

Network Security (Wired)

APOP, SMTP-AUTH, SSL/TLS (IPP, IPPS, HTTP, HTTPS, SMTP, POP3, IMAP4, FTP, LDAP, LDAPS, TFTP, TFTPS), SNMP v3, 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), OAuth 2.0 (SMTP, POP3, IMAP4), Kerberos, IPsec

Network Security (Wireless)

APOP, SMTP-AUTH, SSL/TLS (IPP, IPPS, HTTP, HTTPS, SMTP, POP3, IMAP4, FTP, LDAP, LDAPS, TFTP, TFTPS), SNMP v3, 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), OAuth 2.0 (SMTP, POP3, IMAP4), Kerberos, IPsec

Wireless Network Security *1

WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES)

Wireless Setup Support Utility WPS

Yes

*1
Wi-Fi Direct supports WPA2-PSK (AES) only.

Computer Requirements Specifications

Supported Operating Systems And Software Functions

Computer Platform & Operating System Version Computer Interface Processor Hard Disk Space to Install *1

USB *2

Wired LAN Wireless LAN For Drivers For Applications (Including Drivers)

Windows 10 Home *3 *4

Windows 10 Pro *3 *4

Windows 10 Education *3 *4

Windows 10 Enterprise *3 *4

Printing

PC Fax *5

Scanning

32 bit (x86) or 64 bit (x64) processor

80 MB

2.0 GB

Windows 11 Home *3 *4

Windows 11 Pro *3 *4

Windows 11 Education *3 *4

Windows 11 Enterprise *3 *4

64 bit (x64) processor

Windows Server 2016

Windows Server 2019

Windows Server 2022

Printing

Scanning

Printing

64 bit (x64) processor

80 MB

80 MB

macOS v13 *6

macOS v14 *6

macOS v15 *6

Printing

PC Fax (Send) *5

Scanning

64 bit processor

N/A

500 MB

ChromeOS™

Printing

Scanning

N/A

N/A

N/A

Linux

(Supported Package Management System: dpkg, rpm)

 *7

Printing

PC Fax (Send) *5

Scanning

32bit (x86) or 64bit (x64) processor

20 MB

20 MB

*1
An Internet connection is required to install the software.
*2
Third party USB ports are not supported.
*3
For WIA, 1200 x 1200 resolution.
*4
PaperPort™ 14SE supports Windows 10 and Windows 11.
*5
PC Fax supports black and white only.
*6

macOS Disclaimer

AirPrint capable: Printing, scanning, or PC faxing (Send) via macOS requires the use of AirPrint. Mac drivers are not provided for this machine.

*7
The driver is known to work on the following Linux Distributions.

Red Hat Enterprise Linux 8.6 64bit, Red Hat Enterprise Linux 9.1 64bit, Fedora 39 64bit, Mageia 9 32bit, Mageia 9 64bit, openSUSE 15.5 64bit, SUSE Enterprise15-SP4 64bit, Debian 12.2.0 32bit, Debian 12.2.0 64bit, Ubuntu MATE 18.04 32bit, Ubuntu 22.04 64bit, Ubuntu 23.10 64bit, Linux Mint 21.2 64bit, Ubuntu 24.04 64bit.

For the latest driver updates, go to your model's Downloads page at support.brother.com/downloads.

For the latest supported OS, go to your model's Supported OS page at support.brother.com/os.
