Home > Appendix > Specifications

Specifications

General Specifications

Printer Type

Inkjet

Print Head
Mono

Piezo with 210 nozzles x 1

Colour

Piezo with 70 nozzles x 3 (DCP-J1310DW/DCP-J1360DW)

Piezo with 210 nozzles x 3 (MFC-J4350DW/MFC-J4355DW/MFC-J4555DW)

Memory Capacity

  • 256 MB

Liquid Crystal Display (LCD)
  • DCP-J1310DW/DCP-J1360DW/MFC-J4350DW/MFC-J4355DW

    1.8 in. (4.5 cm) TFT Colour LCD *1

  • MFC-J4555DW

    2.7 in. (6.8 cm) TFT Colour Touchscreen LCD *1

Power Source

AC 100 to 120 V 50/60 Hz (Taiwan)

AC 220 to 240 V 50/60 Hz (Other countries)

Power Consumption *2

  • DCP-J1360DW (Taiwan)

    Copying *3: Approx. 21 W

    Ready *4: Approx. 2.5 W

    Sleep *4: Approx. 0.6 W

    Power Off *4 *5: Approx. 0.15 W

  • DCP-J1310DW/DCP-J1360DW

    Copying *3: Approx. 21 W

    Ready *4: Approx. 2.5 W

    Sleep *4: Approx. 0.6 W

    Power Off *4 *5: Approx. 0.15 W

  • MFC-J4350DW(Taiwan)

    Copying *3: Approx. 21 W

    Ready *4: Approx. 3.0 W

    Sleep *4: Approx. 0.8 W

    Power Off *4 *5: Approx. 0.10 W

  • MFC-J4350DW/MFC-J4355DW

    Copying *3: Approx. 21 W

    Ready *4: Approx. 3.5 W

    Sleep *4: Approx. 0.8 W

    Power Off *4 *5: Approx. 0.10 W

  • MFC-J4555DW

    Copying *3: Approx. 22 W

    Ready *4: Approx. 3.5 W

    Sleep *4: Approx. 0.9 W

    Power Off *4 *5: Approx. 0.10 W

Dimensions

  • DCP-J1310DW


  • DCP-J1360DW


  • MFC-J4350DW/MFC-J4355DW


  • MFC-J4555DW


Weights

  • DCP-J1310DW

    6.3 kg

  • DCP-J1360DW

    7.6 kg

  • MFC-J4350DW/MFC-J4355DW

    8.9 kg

  • MFC-J4555DW

    10.4 kg

Noise Level
Sound Pressure *6
Operating
  • DCP-J1310DW
    • Printing

      55.0 dB (A) (Approx.)

    • Copying (using the scanner glass)

      53.0 dB (A) (Approx.)

  • DCP-J1360DW
    • Printing

      55.0 dB (A) (Approx.)

    • Copying (using the scanner glass)

      53.0 dB (A) (Approx.)

  • MFC-J4350DW/MFC-J4355DW/MFC-J4555DW
    • Printing

      54.0 dB (A) (Approx.)

    • Copying (using the scanner glass)

      51.0 dB (A) (Approx.)

Temperature
Operating

10 to 35°C

Best Print Quality

20 to 33°C

Humidity
Operating

20 to 80% (without condensation)

Best Print Quality

20 to 80% (without condensation)

Automatic Document Feeder (ADF)

(DCP-J1360DW/MFC-J4350DW/MFC-J4355DW/MFC-J4555DW)

Up to 20 pages

Paper: 80 gsm

*1
Measured diagonally
*2
Measured when the machine is connected to the USB interface. Power consumption varies slightly depending on the usage environment or part wear.
*3

(DCP-J1310DW) When single-sided printing, resolution: standard / document: ISO/IEC 24712 printed pattern.

(DCP-J1360DW/MFC-J4350DW/MFC-J4355DW/MFC-J4555DW) When using ADF, single-sided printing, resolution: standard / document: ISO/IEC 24712 printed pattern.

*4
Measured according to IEC 62301 Edition 2.0.
*5
Even when the machine is turned off, it will automatically turn itself on periodically for print head maintenance, and then turn itself off.
*6
Noise depends on printing conditions.

Document Size Specifications

Document Size
ADF Width

(DCP-J1360DW/MFC-J4350DW/MFC-J4355DW/MFC-J4555DW)

139.7 to 215.9 mm

ADF Length *1

(DCP-J1360DW/MFC-J4350DW/MFC-J4355DW/MFC-J4555DW)

  • DCP-J1360DW

    210 to 355.6 mm

  • MFC-J4350DW/MFC-J4355DW/MFC-J4555DW

    148 to 355.6 mm

Scanner Glass Width

Max. 215.9 mm

Scanner Glass Length

Max. 297 mm

*1
Documents that are longer than 297 mm must be fed one page at a time.

Print Media Specifications

Paper Input

Paper Tray #1

Paper Type *1

Plain Paper, Inkjet Paper (coated paper), Glossy Paper, Recycled Paper

Paper Size *2

  • A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive, B5 (JIS), A5, B6 (JIS), A6, Envelopes (C5, Com-10, DL, Monarch), Photo (10 x 15 cm), Photo L (9 x 13 cm), Photo 2L (13 x 18 cm), Index card (13 x 20 cm)

Maximum Paper Capacity

Up to 150 sheets of 80 gsm plain paper

Paper Tray #2

(MFC-J4555DW)

Paper Type

Plain Paper, Recycled Paper

Paper Size *2

A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive, B5 (JIS), A5

Maximum Paper Capacity

Up to 250 sheets of 80 gsm plain paper

Manual Feed Slot

(MFC-J4350DW/MFC-J4355DW/MFC-J4555DW)
Paper Type *1

Plain Paper, Inkjet Paper (coated paper), Glossy Paper, Recycled Paper

Paper Size *2

A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive, B5 (JIS), A5, B6 (JIS), A6, Envelopes (C5, Com-10, DL, Monarch), Photo (10 x 15 cm), Photo L (9 x 13 cm), Photo 2L (13 x 18 cm), Index card (13 x 20 cm)

Maximum Paper Capacity

Up to 1 sheet

Paper Output *1 *3
  • DCP-J1310DW/DCP-J1360DW

    Up to 50 sheets of 80 gsm Plain Paper (face up print delivery to the output paper tray)

  • MFC-J4350DW/MFC-J4355DW/MFC-J4555DW

    Up to 100 sheets of 80 gsm Plain Paper (face up print delivery to the output paper tray)

*1
For glossy paper, remove any printed pages from the output paper tray immediately to avoid smudging.
*2
B5 (JIS) and B6 (JIS) size paper are supported only in some countries.
*3
Actual output tray capacity may vary depending on environmental conditions.

Fax Specifications


This feature is available for MFC-J4350DW/MFC-J4355DW/MFC-J4555DW.

Compatibility

ITU-T Group 3

Modem Speed

Automatic Fallback: 14,400 bps

Scanning Width

(Single-sided document)

ADF: 208 mm (A4)

Scanner Glass: 204 mm (A4)

Printing Width

204 mm (A4)

Greyscale

Monochrome: 8 bit (256 levels)

Colour: 24 bit (8 bit per colour/256 levels)

Resolution

(Horizontal)

203 dpi

Resolution

(Vertical)

Standard:

98 dpi (Mono)

196 dpi (Colour)

Fine:

196 dpi (Mono)

196 dpi (Colour)

Superfine:

392 dpi (Mono)

Photo:

196 dpi (Mono)

Address Book

40 numbers (MFC-J4350DW/MFC-J4355DW)

100 names x 2 numbers (MFC-J4555DW)

Groups

Up to 6

Broadcasting

90 (40 Address Book/50 Manual Dial) (MFC-J4350DW/MFC-J4355DW)

250 (200 Address Book/50 Manual Dial) (MFC-J4555DW)

Automatic Redial

3 times at 5 minute intervals

Memory Transmission

MFC-J4350DW/MFC-J4355DW: Up to 170 pages *1

MFC-J4555DW: Up to 180 pages *1

Out of Paper Reception

MFC-J4350DW/MFC-J4355DW: Up to 170 pages *1

MFC-J4555DW: Up to 180 pages *1

*1
‘Pages’ refers to the ‘ITU-T Test Chart #1’ (a typical business letter, Standard resolution, MMR code).

Copy Specifications

Colour/Monochrome

Yes/Yes

Copy Width

204 mm *1

Multiple Copies

Stacks/Sorts up to 99 pages

Enlarge/Reduce

25% to 400% (in increments of 1%)

Resolution

Prints up to 1200 × 1800 dpi (DCP-J1310DW/DCP-J1360DW)

Prints up to 1200 × 2400 dpi (MFC-J4350DW/MFC-J4355DW/MFC-J4555DW)

*1
When copying on A4 size paper.

USB Flash Drive Specifications

This function is available for MFC-J4555DW.
Compatible Media *1

USB Flash drive *2

JPEG Print

Resolution

Up to 1200 x 4800 dpi (MFC-J4555DW)

Paper Type

Plain Paper, Inkjet Paper (coated paper), Glossy Paper

Paper Size

A4, Letter, Photo (10 x 15 cm), Photo 2L (13 x 18 cm)

File Format

JPEG (Progressive JPEG format is not supported)

Scan to Media
File Format

JPEG, PDF (Colour, Grey)

TIFF, PDF (Monochrome)

*1
USB Flash drives are not supplied with product.
*2
Hi-Speed USB 2.0. USB Mass Storage standard. Supported formats: FAT12/FAT16/FAT32/exFAT

Scanner Specifications

Colour/Monochrome

Yes/Yes

TWAIN Compliant

Yes

(Windows 10 / Windows 11)

WIA Compliant

Yes

(Windows 10 / Windows 11)

Colour Depth

30 bit colour processing (Input)

24 bit colour processing (Output)

Greyscale

10 bit colour processing (Input)

8 bit colour processing (Output)

Resolution

Up to 19200 × 19200 dpi (interpolated) *1 *2

(from Scanner Glass)

Up to 1200 × 2400 dpi (optical)

(from ADF) *3

Up to 1200 × 600 dpi (optical)

Scanning Width and Length

(Single-sided document)

(Scanner Glass)

Width: Up to 213.9 mm

Length: Up to 295 mm

(ADF) *3

Width: Up to 213.9 mm

Length: Up to 353.6 mm

*1
The TWAIN driver only (Maximum 1200 × 1200 dpi scanning with the WIA driver in Windows 10 and Windows 11.)
*2
The scanning range may decrease as the scanning resolution increases.
*3
ADF models only

Printer Specifications

Resolution
  • DCP-J1310DW/DCP-J1360DW

    Up to 1200 × 6000 dpi (Windows only)

  • MFC-J4350DW/MFC-J4355DW/MFC-J4555DW

    Up to 1200 × 4800 dpi

Printing Width *1

204 mm

Borderless *2: 210 mm

Borderless

A4, Letter, A6, Photo (10 x 15 cm), Photo L (9 x 13 cm), Photo 2L (13 x 18 cm), Index card (13 x 20 cm)

Automatic 2-sided Printing

Paper Type

Plain Paper, Recycled Paper

Paper Size *3

A4, Letter, Executive, A5, B5 (JIS), B6 (JIS)
Print Speed

See your model's page on your local Brother website.

*1
When printing on A4 size paper.
*2
When the Borderless feature is set to On.
*3
B5 (JIS) and B6 (JIS) size paper are supported only in some countries.

Interface Specifications

USB *1 *2

Use a USB 2.0 interface cable (Type A/B) that is no longer than 2 m.

LAN

(MFC-J4555DW)

Use an Ethernet UTP cable category 5 or greater.

Wireless LAN

IEEE 802.11a/b/g/n (Infrastructure)

IEEE 802.11a/g/n (Wi-Fi Direct)

*1
Your machine has a USB 2.0 Hi-Speed interface. The machine can also be connected to a computer that has a USB 1.1 interface.
*2
Third party USB ports are not supported.

Network Specifications

  • (DCP-J1310DW/DCP-J1360DW)

    You can connect your machine to a network for Network Printing and Network Scanning.

  • (MFC-J4350DW/MFC-J4355DW/MFC-J4555DW)

    You can connect your machine to a network for Network Printing, Network Scanning, PC-Fax Send, and PC-Fax Receive (Windows only).

Network Security (Wired)

(MFC-J4555DW)

SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, FTP, LDAP), SNMP v3, 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), OAuth (SMTP), Kerberos, IPsec

Network Security (Wireless)

(DCP-J1310DW/DCP-J1360DW/MFC-J4350DW/MFC-J4355DW)

SSL/TLS (IPPS, HTTPS), 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)

Network Security (Wireless)

(MFC-J4555DW)

SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, FTP, LDAP), SNMP v3, 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), OAuth (SMTP), Kerberos, IPsec

Wireless Network Security  *1

WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES)

Wireless Setup Support Utility WPS

Yes

*1
Wi-Fi Direct supports WPA2-PSK (AES) only.

Computer Requirements Specifications

Supported Operating Systems And Software Functions

Computer Platform & Operating System Version Computer Interface Processor

Hard Disk Space to Install *1

USB *2

Wired LAN *3 Wireless LAN For Drivers For Applications (Including Drivers)

Windows 10 Home *4 *5

Windows 10 Pro *4 *5

Windows 10 Education *4 *5

Windows 10 Enterprise *4 *5

Printing

PC Fax *6

Scanning

32 bit (x86) or 64 bit (x64) processor

80 MB

2.0 GB

Windows 11 Home *4 *5

Windows 11 Pro *4 *5

Windows 11 Education *4 *5

Windows 11 Enterprise *4 *5

64 bit (x64) processor

Windows Server 2016

Windows Server 2019

Windows Server 2022

Printing

Scanning

Printing

64 bit (x64) processor

80 MB

80 MB

macOS v13 *7

macOS v14 *7

macOS v15 *7

Printing

PC Fax (Send) *6

Scanning

64 bit processor

N/A

500 MB

ChromeOS™

Printing

Scanning

N/A

N/A

N/A

Linux

(Supported Package Management System: dpkg, rpm) *8

Printing

PC Fax (Send) *6

Scanning

32 bit (x86) or 64 bit (x64) processor

20 MB

20 MB

*1
An Internet connection is required to install the software.
*2
Third party USB ports are not supported.
*3
MFC-J4555DW only.
*4
For WIA, 1200 x 1200 resolution.
*5
PaperPort™ 14SE supports Windows 10 and Windows 11.
*6
PC Fax supports black and white only. (For models with facsimile function)
*7
macOS Disclaimer

AirPrint capable: Printing, scanning, or PC faxing(Send) via macOS requires the use of AirPrint. Mac drivers are not provided for this machine.

*8
The driver is known to work on the following Linux Distributions.

Red Hat Enterprise Linux 8.6 64bit, Red Hat Enterprise Linux 9.1 64bit, Fedora 39 64bit, Mageia 9 32bit, Mageia 9 64bit, openSUSE 15.5 64bit, SUSE Enterprise15-SP4 64bit, Debian 12.2.0 32bit, Debian 12.2.0 64bit, Ubuntu MATE 18.04 32bit, Ubuntu 22.04 64bit, Ubuntu 23.10 64bit, Linux Mint 21.2 64bit, Ubuntu 24.04 64bit.

For the latest driver updates, go to your model's Downloads page at support.brother.com/downloads.

For the latest supported OS, go to your model's Supported OS page at support.brother.com/os.

All trademarks, brand and product names are the property of their respective companies.
