Specifications

General Specifications

Printer Type

Inkjet

Print Head
Mono

Piezo with 210 nozzles x 1

Colour
  • DCP-T520W/DCP-T525W

    Piezo with 70 nozzles x 3

  • DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW

    Piezo with 210 nozzles x 3

Memory Capacity

128 MB

Liquid Crystal Display (LCD)
  • DCP-T520W/DCP-T525W/DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW

    1 line LCD

  • MFC-T920DW/MFC-T925DW *1

    1.8 in. (44.9 mm) TFT Colour LCD

Power Source

AC 100 to 120 V 50/60 Hz (Taiwan)

AC 220 to 240 V 50/60 Hz (Other countries)

Power Consumption *2

  • DCP-T520W/DCP-T525W (Taiwan)

    Copying *3: Approx. 16 W

    Ready *5: Approx. 2.5 W

    Sleep *5: Approx. 0.8 W

    Power Off *5 *6: Approx. 0.2 W

  • DCP-T520W/DCP-T525W

    Copying *3: Approx. 16 W

    Ready *5: Approx. 3 W

    Sleep *5: Approx. 0.8 W

    Power Off *5 *6: Approx. 0.2 W

  • DCP-T720DW/DCP-T725DW

    Copying *4: Approx. 16 W

    Ready *5: Approx. 3 W

    Sleep *5: Approx. 0.8 W

    Power Off *5 *6: Approx. 0.2 W

  • DCP-T820DW/DCP-T825DW (Taiwan)

    Copying *4: Approx. 16 W

    Ready *5: Approx. 3 W

    Sleep *5: Approx. 0.9 W

    Power Off *5 *6: Approx. 0.2 W

  • DCP-T820DW/DCP-T825DW

    Copying *4: Approx. 17 W

    Ready *5: Approx. 3 W

    Sleep *5: Approx. 0.9 W

    Power Off *5 *6: Approx. 0.2 W

  • MFC-T920DW/MFC-T925DW (Taiwan)

    Copying *4: Approx. 19 W

    Ready *5: Approx. 3.5 W

    Sleep *5: Approx. 1.2 W

    Power Off *5 *6: Approx. 0.2 W

  • MFC-T920DW/MFC-T925DW

    Copying *4: Approx. 17 W

    Ready *5: Approx. 4 W

    Sleep *5: Approx. 1.2 W

    Power Off *5 *6: Approx. 0.2 W

Dimensions

  • DCP-T520W/DCP-T525W


  • DCP-T720DW/DCP-T725DW


  • DCP-T820DW/DCP-T825DW


  • MFC-T920DW/MFC-T925DW


Weights

  • DCP-T520W/DCP-T525W (Taiwan)

    7.2 kg

  • DCP-T520W/DCP-T525W

    7.3 kg

  • DCP-T720DW/DCP-T725DW(Taiwan)

    8.6 kg

  • DCP-T720DW/DCP-T725DW

    8.7 kg

  • DCP-T820DW/DCP-T825DW (Taiwan)

    9.5 kg

  • DCP-T820DW/DCP-T825DW

    9.6 kg

  • MFC-T920DW/MFC-T925DW (Taiwan)

    9.6 kg

  • MFC-T920DW/MFC-T925DW

    9.7 kg

Noise Level
Sound Pressure
Operating

53.5 dB (A) (Approx.) *7

Temperature
Operating

10 to 35°C

Best Print Quality

20 to 33°C

Humidity
Operating

20 to 80% (without condensation)

Best Print Quality

20 to 80% (without condensation)

Automatic Document Feeder (ADF)

(DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW)

Up to 20 pages

Paper: 80 gsm

*1
Measured diagonally
*2
Measured when the machine is connected to the USB interface. Power consumption varies slightly depending on the usage environment or part wear.
*3
When single-sided printing, resolution: standard / document: ISO/IEC 24712 printed pattern.
*4
When using ADF, single-sided printing, resolution: standard / document: ISO/IEC 24712 printed pattern.
*5
Measured according to IEC 62301 Edition 2.0.
*6
Even when the machine is turned off, it will automatically turn itself on periodically for print head maintenance, and then turn itself off.
*7
Noise depends on printing conditions.

Document Size Specifications

Document Size
ADF Width

(DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW)

148 to 215.9 mm

ADF Length *1

(DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW)

148 to 355.6 mm

Scanner Glass Width

Max. 215.9 mm

Scanner Glass Length

Max. 297 mm

*1
Documents that are longer than 297 mm must be fed one page at a time.

Print Media Specifications

Paper Input
Paper Tray
Paper Type *1

Plain Paper, Inkjet Paper (coated paper), Glossy Paper, Recycled Paper

Paper Size *2

A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive, B5 (JIS), A5, B6 (JIS), A6, Envelopes (C5, Com-10, DL, Monarch), Photo (4" x 6")/(10 x 15 cm), Photo 2L (5" x 7")/(13 x 18 cm), Index card (5" x 8")/(13 x 20 cm)

Maximum Paper Capacity

Up to 150 sheets of 80 gsm plain paper

Multi-purpose tray (MP tray) *3

(DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW)

Paper Type *1

Plain Paper, Inkjet Paper (coated paper), Glossy Paper, Recycled Paper

Paper Size *2 *4

A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive, B5 (JIS), A5, B6 (JIS), A6, Envelopes (C5, Com-10, DL, Monarch), Photo (4" x 6")/(10 x 15 cm), Photo L (3.5" x 5")/(9 x 13 cm), Photo 2L (5" x 7")/(13 x 18 cm), Index card (5" x 8")/(13 x 20 cm)

Maximum Paper Capacity *4

Up to 80 sheets of 80 gsm Plain Paper

Manual Feed Slot

(DCP-T520W/DCP-T525W/DCP-T720DW/DCP-T725DW)
Paper Type *1

Plain Paper, Inkjet Paper (coated paper), Glossy Paper, Recycled Paper

Paper Size *2

A4, Letter, Legal, Mexico Legal, India Legal, Folio, Executive, B5 (JIS), A5, B6 (JIS), A6, Envelopes (C5, Com-10, DL, Monarch), Photo (4" x 6")/(10 x 15 cm), Photo L (3.5" x 5")/(9 x 13 cm), Photo 2L (5" x 7")/(13 x 18 cm), Index card (5" x 8")/(13 x 20 cm)

Maximum Paper Capacity

Up to 1 sheet

Paper Output *1

Up to 50 sheets of 80 gsm Plain Paper (face up print delivery to the output paper tray)

*1
For glossy paper, remove any printed pages from the output paper tray immediately to avoid smudging.
*2
Legal, Mexico Legal, India Legal, Folio, B5 (JIS) and B6 (JIS) size paper are supported only in some countries.
*3
We recommend using the MP tray for glossy paper.
*4
You can load only one sheet of paper that is larger than Letter/A4 size into the MP tray at a time.

Fax Specifications


This feature is available for MFC models.

Compatibility

ITU-T Group 3

Modem Speed

Automatic Fallback: 14,400 bps

Scanning Width

(Single-sided document)

ADF: 208 mm (A4)

Scanner Glass: 204 mm (A4)

Printing Width

204 mm (A4)

Resolution

(Horizontal)

203 dpi

Resolution

(Vertical)

Standard:

98 dpi (Mono)

Fine:

196 dpi (Mono)

Superfine:

392 dpi (Mono)

Photo:

196 dpi (Mono)

Address Book

40 numbers (MFC-T920DW/MFC-T925DW)

Groups

Up to 6

Broadcasting

90 (40 Address Book/50 Manual Dial) (MFC-T920DW/MFC-T925DW)

Automatic Redial

3 times at 5 minute intervals

Memory Transmission

Up to 170 pages (MFC-T920DW/MFC-T925DW) *1

Out of Paper Reception

Up to 170 pages (MFC-T920DW/MFC-T925DW) *1

*1
‘Pages’ refers to the ‘ITU-T Test Chart #1’ (a typical business letter, Standard resolution, MMR code).

Copy Specifications

Colour/Monochrome

Yes/Yes

Copy Width

204 mm *1

Multiple Copies

Stacks/Sorts up to 99 pages

Enlarge/Reduce

25% to 400% (in increments of 1%)

Resolution

Prints up to 1200 × 1800 dpi (DCP-T520W/DCP-T525W)

Prints up to 1200 × 2400 dpi (DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW)

*1
When copying on A4 size paper.

PhotoCapture Center Specifications


This function is available for MFC-T920DW/MFC-T925DW.

Compatible Media *1

USB Flash drive *2

Resolution

Up to 1200 x 6000 dpi (MFC-T920DW/MFC-T925DW)

Paper Type

Plain Paper, Inkjet Paper (coated paper), Glossy Paper, Brother BP71 paper

Paper Size

A4, Letter, Photo (10 x 15 cm), Photo 2L (13 x 18 cm)

File Format

JPEG (Progressive JPEG format is not supported)

Scan to Media
File Format

JPEG, PDF (Colour, Grey)

TIFF, PDF (Monochrome)

*1
USB Flash drives are not supplied with product.
*2
Hi-Speed USB 2.0. USB Mass Storage standard. Supported formats: FAT12/FAT16/FAT32/exFAT

Scanner Specifications

Colour/Monochrome

Yes/Yes

TWAIN Compliant

Yes

(Windows 7 SP1 / Windows 8.1 / Windows 10 / Windows 11)

WIA Compliant

Yes

(Windows 7 SP1 / Windows 8.1 / Windows 10 / Windows 11)

Colour Depth

30 bit colour processing (Input)

24 bit colour processing (Output)

Greyscale

10 bit colour processing (Input)

8 bit colour processing (Output)

Resolution

Up to 19200 × 19200 dpi (interpolated) *1 *2

(from Scanner Glass)

Up to 1200 × 2400 dpi (optical)

(from ADF) *3

Up to 1200 × 600 dpi (optical)

Scanning Width and Length

(Single-sided document)

(Scanner Glass)

Width: Up to 213.9 mm

Length: Up to 295 mm

(ADF) *3

Width: Up to 213.9 mm

Length: Up to 353.6 mm

*1
Maximum 1200 × 1200 dpi scanning with the WIA driver in Windows 7 SP1, Windows 8.1, Windows 10 and Windows 11 (resolution up to 19200 × 19200 dpi can be selected using the scanner utility).
*2
The scanning range may decrease as the scanning resolution increases.
*3
ADF models only

Printer Specifications

Resolution

Up to 1200 × 6000 dpi (Windows only) (DCP-T520W/DCP-T525W)

Up to 1200 × 6000 dpi (DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW)

Printing Width *1

204 mm

Borderless *2: 210 mm

Borderless

A4, Letter, A6, Photo (10 x 15 cm), Photo L (9 x 13 cm), Photo 2L (13 x 18 cm), Index card (13 x 20 cm)

Automatic 2-sided

(DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW)

Paper Type

Plain Paper, Recycled Paper

Paper Size *3

A4, Letter, Executive, A5, B5 (JIS)

Print Speed

See your model's page on your local Brother website.

*1
When printing on A4 size paper.
*2
When the Borderless feature is set to On.
*3
B5 (JIS) size paper is supported only in some countries.

Interface Specifications

USB *1 *2

Use a USB 2.0 interface cable that is no longer than 2 m.

LAN

(DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW)

Use an Ethernet UTP cable category 5 or greater.

Wireless LAN

IEEE 802.11b/g/n (Infrastructure)

IEEE 802.11g/n (Wi-Fi Direct)

*1
Your machine has a USB 2.0 Hi-Speed interface. The machine can also be connected to a computer that has a USB 1.1 interface.
*2
Third party USB ports are not supported.

Network Specifications

  • (DCP-T520W/DCP-T525W/DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW)

    You can connect your machine to a network for Network Printing and Network Scanning.

  • (MFC-T920DW/MFC-T925DW)

    You can connect your machine to a network for Network Printing, Network Scanning, PC-Fax Send, PC-Fax Receive (Windows only).

Network Security (Wired)

(DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW)

SSL/TLS (IPPS, HTTPS)

Network Security (Wireless)

SSL/TLS (IPPS, HTTPS)

Wireless Network Security

SSID (32 characters), WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES)

Wireless Setup Support Utility WPS

Yes

Computer Requirements Specifications

Supported Operating Systems And Software Functions

Computer Platform & Operating System Version PC Interface Processor

Hard Disk Space to Install *1

USB *2

Wired LAN *3

WLAN(Wi-Fi) For Drivers For Applications (Including Drivers)

Windows Operating System

Windows 7 SP1 *4 *5 *6

Windows 8.1 *4 *5

Printing

PC Fax *7

Scanning

32 bit (x86) or 64 bit (x64) processor

650 MB

1.3 GB

Windows 10 Home *4 *5

Windows 10 Pro *4 *5

Windows 10 Education *4 *5

Windows 10 Enterprise *4 *5

Windows 11 Home *4 *5

Windows 11 Pro *4 *5

Windows 11 Education *4 *5

Windows 11 Enterprise *4 *5

64 bit (x64) processor

Windows Server 2008 *6

Printing

Scanning

Printing

32 bit (x86) or 64 bit (x64) processor

80 MB

80 MB

Windows Server 2008 R2 *6

Windows Server 2012

Windows Server 2012 R2

Windows Server 2016

Windows Server 2019

Windows Server 2022

64 bit (x64) processor

Mac Operating System *8

macOS v10.15.x

macOS v11

macOS v12

Printing

PC Fax (Send) *7 *9

Scanning

64 bit processor

N/A

550 MB

*1
An Internet connection is required to install the software if the Brother installation disc is not supplied.
*2
Third party USB ports are not supported.
*3
DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW only
*4
For WIA, 1200 x 1200 resolution. Brother Scanner Utility enables enhancing up to 19200 x 19200 dpi.
*5
Nuance™ PaperPort™ 14SE supports Windows 7 SP1, Windows 8.1, Windows 10 and Windows 11.
*6
Windows 7 SP1 / Windows Server 2008 / Windows Server 2008 R2 supported by Extend Security Updates until Jan 10, 2023.
*7
PC Fax supports black and white only. (MFC models)
*8
macOS Disclaimer

AirPrint capable: Printing or scanning via macOS requires the use of AirPrint. Mac drivers are not provided for this machine.

*9
AirPrint only.

For the latest driver updates, go to your model's Downloads page at support.brother.com.
